Panel Design (Part 5)

Below is Panel Design #5 from Aerotronics (sent to us on June 7, 2021) with the following changes:

1. An “EFIS STANDBY BATTERY” switch was added to the left side of the panel with the “Mag” switches

2. The yellow “EFIS BATT MASTER” switch was removed from the row of switches under the G3X

3. All of the switches were equally spaced out under the G3X

4. The “BATTERY MASTER” switch was renamed “MAIN BATT”

5. The “ALT FIELD” switch was renamed “MAIN ALT”
